外螺紋骨架油封-Turcon Radial oil seal TRP
Technical data
Pressure: up to 0.5 MPa
Temperature: -40 °C to +200 °C
(depending on material)
Speed: up to 10 m/s
(depending on pressure and material)
Media: mineral and synthetic lubricants
(CLP, HLP, APGL etc.)
Advantages
- Good static sealing
- Compensation of different thermal expansion
- Reduced risk of fretting corrosion
- Up to 0.5 MPa pressure at moderate peripheral speed
- Low lip and shaft wear at low pressure run
- Effective protection against air side contaminants
- No need of back-up ring
Application examples
- Transmission systems (e.g. gearboxes)
- Pumps
- Hydraulic motors
- Machinery industry
Standard material
NBR (70 Shore A)
NBR (75 Shore A)
FKM (70 Shore A) l
FKM (75 Shore A)
